Simrad AC85 Autopilot Computer

SKU: 000-10189-001

Customizable autopilot computer that can be configured with up to four drive boards depending on the installation requirements.
$2,000
Find a dealer

Product details

Drive computer cabinet with CAN-bus supply and 4 channel IEC 61162-1 (NMEA 0183) RX/TX (not mounted). Prepared for internal mounting of up to three additional drive boards with the same functionality as the Simrad SD80 or AD80 interface units, or AC70 autopilot computer.

Key Features

  • Configurable for use with up to three drive interface boards
  • CAN-bus supply
  • 4 channel IEC 61162-1 (NMEA 0183) RX/TX (not mounted)
  • Bulkhead mounted

What's in the box?

  • AC85 CABINET
  • SI80 PCB ASSEMBLY

Specifications

Compass Safe
1 m (39,37")
Supply Voltage
12/24VDC +30 -10%
Operating Temperature Range
-15 to +55C (5 to 131F)
Warranty Period
2 years
Storage Temperature Range
-30C to +70C (-22F to +158F)
Weight
4,1 kg (9 lbs) (Basic)
Dimensions W x H x D
408 X 440 X 106mm(16,06 x 17,32x 4,17")
Mounting Type
Bulkhead
Rudder sensor s upport
Config. dependant
Engine Drive systems integration
Config. dependant
Drive output
Config. dependant
Recommended Fuse Rating
Config. dependant
Power Consumption max
Config. dependant
Power Consumption typical
Config. dependant
NMEA 2000 Connectivity
Config. Dependant (Max 10)
NMEA 0183 Sentences supported
Input: AAM, ACK, APB, BOD, BWC, DPT, GGA, GLL, HDG, HDT, HSC, RMA, RMB, RMC, ROT, THS, TNT, VBW, VHW, VLW, VTG, ZDA. Output SI80 Ch1: ACK, ALR, HDG (1Hz) or HDT (1Hz), HTD, RSA (3Hz), THS (3Hz). Output SI80 Ch2: HDG (10Hz) or HDT (10Hz), ROT (3Hz), RSA (5Hz). Output SI80 Ch3: GGA, GLL, HTD, RSA (5Hz), THS (10Hz), TNT, VTG, ZDA. Output SI80 Ch4: ACK, ALR, GGA, GLL, HTD, RSA (5Hz), THS (10Hz)
Waterproofrating
IPx4
Compasssensor support
NMEA2000, NMEA0183
